D-CB-28LP
STANDARD PRECAST CIRCULAR NO. 31 CATCH BASIN (FOR USE UNDER CONCRETE MEDIAN BARRIER WALL)
(Click image to open PDF)
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| D-CB-99 | MISCELLANEOUS DETAILS FOR RECTANGULAR STRUCTURES | REINFORCEMENT REQUIREMENTS AROUND PIPE OPENINGS |
| D-CBB-12C | TYPE "B" CAST IRON FRAME, GRATE & 4" MOUNTABLE INLET DETAILS FOR NOS. 28 AND 29 TYPE CATCH BASINS | DETAILS OF CAST IRON GRATES, FRAMES AND CURB INLETS |
| D-PB-2 | STANDARD DETAILS FOR FLEXIBLE PIPE INSTALLATION | GASKET DETAILS FOR FLEXIBLE PIPE |
| D-RF-1 | STANDARD PRECAST RISER | PRECAST CONCRETE RISER FRAME DETAILS |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION | REMARKS |
|---|---|---|---|
| 611-28.01 | EACH | CATCH BASINS, TYPE 28, 0' - 4' DEPTH | |
| 611-28.02 | EACH | CATCH BASINS, TYPE 28, > 4' - 8' DEPTH | |
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 05-27-1999 | 12-18-2000 | 05-27-2001 | 07-29-2004 | 08-01-2012| 05-15-2018 |
