D-SLD-1
SLOTTED DRAINS
(Click image to open PDF)
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| D-SLD-2 | SLOTTED DRAINS | ADDITIONAL DETAILS |
| D-SLD-3 | SLOTTED DRAINS | ADDITIONAL DETAILS |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION | REMARKS | ||
|---|---|---|---|---|---|
| 204-08.01 | C.Y. | BACKFILL MATERIAL (FLOWABLE FILL) | |||
| 204-07 | C.Y. | BEDDING MATERIAL (PIPE) CLASS B | |||
| 702-03 | C.Y. | CONCRETE COMBINED CURB & GUTTER | |||
| 607-37.01 | L.F. | 15" CORRUGATED METAL PIPE CULVERT | |||
| 607-37.02 | L.F. | 18" CORRUGATED METAL PIPE CULVERT | |||
| 607-37.03 | L.F. | 24" CORRUGATED METAL PIPE CULVERT | |||
| 607-37.04 | L.F. | 30" CORRUGATED METAL PIPE CULVERT | |||
| 607-37.05 | L.F. | 36" CORRUGATED METAL PIPE CULVERT |
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 01-28-1992 | 10-26-1995 | 07-29-1996 | 10-26-1996 | 12-18-1997 | 05-27-2001 | 02-02-2016 | 02-20-2020 |
