MM-VPR-1
VEHICLE AND PEDESTRIAN SAFETY RAIL
(Click image to open PDF)
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| MM-BPR-1 | BIKE AND PEDESTRIAN SAFETY RAIL | WHERE PEDESTRIAN SAFETY RAIL IS WARRANTED |
| MM-BPR-2 | BIKE AND PEDESTRIAN MEDIAN BARRIER RAIL | IN ORDER TO PROVIDE BICYCLE SAFETY |
| MM-SERIES | MULTIMODAL STANDARD DRAWING | FOR SIDEWALK DETAILS |
| MM-TS-2 | LATERAL OFFSETS FOR SIDEWALK AND SHARED USE PATH | FOR PEDESTRIAN FACILITIES |
| RD11-TS SERIES | Roadway Design Standards - RD11 TYPICAL SECTION AND DESIGN CRITERIA | FOR PEDESTRIAN FACILITIES |
| S-CZ-1 | CLEAR ZONE CRITERIA | FOR VEHICLE SAFETY |
| S-GR31 SERIES | Safety Design and Guardrails - GUARDRAIL DETAILS | GUARDRAIL DETAILS AND MATERIAL PROPERTIES NOT SHOW |
| S-GRC-4 | GUARDRAIL CONNECTION TO BRIDGE RAILING CONCRETE PARAPET | FOR ADDITIONAL DETAILS |
| S-PL-1 | SAFETY PLAN AT ROADSIDE HAZARDS | LENGTH OF NEED AS DETERMINED |
| S-PL-6 | SAFETY PLAN SAFETY HARDWARE PLACEMENT ON OUTSIDE EDGE | FOR ADDITIONAL DETAILS |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION | REMARKS |
|---|---|---|---|
| 705-06.27 | L.F. | THRIE BEAM 38IN VEHICLE & PEDESTRIAN SAFETY RAIL MASH TL-3 | |
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 10-16-2020 |
