S-GRS-6
SPECIAL CASE FLEXIBITLTY ON GUARDRAIL POST INSTALLATIONS
(Click image to open PDF)
Latest Revision Note
XX/XX/20XX NEW STANDARD DRAWING
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| RD11-TS-SERIES | RD11 TYPICAL SECTIONS AND DESIGN CRITERIA | FOR SLOPE CRITERIA |
| S-GR31-1C | GUARDRAIL GENERAL NOTES AND POST DETAILS | FOR W-BEAM AND POST DETAILS |
| S-GR31 SERIES | GUARDRAIL DETAILS | FOR GUARDRAIL DETAILS |
| S-GRS-1 | SPECIAL CASE LONG SPAN GUARDRAIL 1 POST, 2 OR 3 POSTS OMITTED | FOR LONG SPAN GUARDRAIL OMITTED POST DETAILS |
| S-PL-6 | SAFETY PLAN SAFETY HARDWARE PLACEMENT ON OUTSIDE EDGE | FOR GUARDRAIL PLACEMENT DETAILS |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION |
|---|---|---|
| 705-06.01 | L.F. | W-BEAM GUARDRAIL (TYPE 2) MASH TL-3 |
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 01-28-2022 |
