EC-STR-31
TEMPORARY DIVERSION CHANNEL
(Click image to open PDF)
Latest Revision Note
05/04/2022 REVISED GENERAL NOTE (R) AND REDREW SHEET.
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| EC-STR-1 | DEWATERING STRUCTURE | FOR INSTALLATION DETAILS AND ITEM NUMBERS FOR DEWATERING STRUCTURE. |
| EC-STR-2 | SEDIMENT FILTER BAGS | FOR INSTALLATION DETAILS AND ITEM NUMBERS FOR SEDIMENT FILTER BAG. |
| EC-STR-3C | SILT FENCE WITH WIRE BACKING | FOR INSTALLATION DETAILS AND ITEM NUMBERS FOR SILT FENCE WITH WIRE BACKING |
| EC-STR-31A | TEMPORARY DIVERSION CHANNEL DESIGN | TO DETERMINE RIPRAP CLASS AND DEPTH |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION | REMARKS |
|---|---|---|---|
| 209-65.03 | L.F. | TEMPORARY DIVERSION CHANNEL | |
| 709-05.06 | TON | MACHINED RIP-RAP (CLASS A-1) | |
| 740-10.03 | S.Y. | GEOTEXTILE (TYPE III)(EROSION CONTROL) |
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 10-26-1992 | 12-18-1995 | 05-27-2001 | 12-18-2002 | 04-15-2006 | 04-01-2008 | 08-01-2012 | 05-04-2022 |
