EC-STR-46
CATCH BASIN FILTER ASSEMBLY (TYPE 6)
(Click image to open PDF)
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| D-CB-10S | STANDARD RECTANGULAR CONCRETE N0. 10 CATCH BASIN | SEE STANDARD DRAWINGS FOR CATCH BASIN DIMENSIONS AND DETAILS |
| D-CB-12P | STANDARD PRECAST RECTANGULAR CONCRETE NO.12 CATCH BASIN | SEE STANDARD DRAWINGS FOR CATCH BASIN DIMENSIONS AND DETAILS |
| D-CB-12S | STANDARD RECTANGULAR CONCRETE NO.12 CATCH BASIN | SEE STANDARD DRAWINGS FOR CATCH BASIN DIMENSIONS AND DETAILS |
| D-CB-13P | STANDARD PRECAST RECTANGULAR CONCRETE NO.13 CATCH BASIN | SEE STANDARD DRAWINGS FOR CATCH BASIN DIMENSIONS AND DETAILS |
| D-CB-13S | STANDARD RECTANGULAR CONCRETE NO. 13 CATCH BASIN | SEE STANDARD DRAWINGS FOR CATCH BASIN DIMENSIONS AND DETAILS |
| D-CB-25P | STANDARD PRECAST RECTANGULAR CONCRETE NO. 25 CATCH BASIN (FOR USE WITH 6" MOUNTABLE CURB) | SEE STANDARD DRAWINGS FOR CATCH BASIN DIMENSIONS AND DETAILS |
| D-CB-25S | STANDARD RECTANGULAR CONCRETE NO. 25 CATCH BASIN (FOR USE WITH 6" MOUNTABLE CURB) | SEE STANDARD DRAWINGS FOR CATCH BASIN DIMENSIONS AND DETAILS |
| D-CB-28P | STANDARD PRECAST RECTANGULAR CONCRETE NO. 28 CATCH BASIN (FOR USE WITH 4" MOUNTABLE CURB) | SEE STANDARD DRAWINGS FOR CATCH BASIN DIMENSIONS AND DETAILS |
| D-CB-28S | STANDARD RECTANGULAR CONCRETE NO. 28 CATCH BASIN (FOR USE WITH 4" MOUNTABLE CURB) | SEE STANDARD DRAWINGS FOR CATCH BASIN DIMENSIONS AND DETAILS |
| D-CB-41P | STANDARD 4'X 3' PRECAST RECTANGULAR CONCRETE NO. 41 CATCH BASIN (FOR USE UNDER CONCRETE MEDIAN BARRIER WALL) | SEE STANDARD DRAWINGS FOR CATCH BASIN DIMENSIONS AND DETAILS |
| D-CB-41S | STANDARD 4'X 3' RECTANGULAR CONCRETE NO. 41 CATCH BASIN (FOR USE UNDER CONCRETE MEDIAN BARRIER WALL) | SEE STANDARD DRAWINGS FOR CATCH BASIN DIMENSIONS AND DETAILS |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION | REMARKS |
|---|---|---|---|
| 209-40.46 | EACH | CATCH BASIN FILTER ASSEMBLY(TYPE 6) | |
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 04-15-2004 |
