EC-STR-59
GABION CHECK DAM GENERAL NOTES AND COMPONENT PROPERTIES
(Click image to open PDF)
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| EC-STR-55 | GABION CHECK DAM | FOR ADDITIONAL DETAILS AND GENERAL NOTES NOT SHOWN ON DRAWING |
| EC-STR-56 | GABION CHECK DAM DESIGN TABLES | FOR ADDITIONAL DETAILS AND GENERAL NOTES NOT SHOWN ON DRAWING |
| EC-STR-57 | GABION ASSEMBLY DETAILS | FOR ADDITIONAL DETAILS AND GENERAL NOTES NOT SHOWN ON DRAWING |
| EC-STR-58 | GABION ASSEMBLY DETAILS | FOR ADDITIONAL DETAILS AND GENERAL NOTES NOT SHOWN ON DRAWING |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION | REMARKS |
|---|---|---|---|
| 209-05 | C.Y. | SEDIMENT REMOVAL | |
| 709-05.06 | TON | MACHINED RIP-RAP (CLASS A-1) | |
| 709-10.01 | C.Y. | GABIONS (DESCRIPTION) | |
| 709-10.02 | C.Y. | GABIONS (DESCRIPTION) | |
| 709-10.03 | C.Y. | GABIONS (DESCRIPTION) | |
| 709-10.04 | C.Y. | GABIONS (DESCRIPTION) | |
| 709-10.05 | C.Y. | GABIONS (DESCRIPTION) | |
| 740-10.03 | S.Y. | GEOTEXTILE (TYPE III)(EROSION CONTROL) |
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 07-29-2004 | 04-15-2006 | 04-01-2008 | 08-01-2012 |
